| Image Format |
1/3" DSP Color, Sharp |
| Effective Pixels |
NTSC : 512(H) X 492(V)
PAL : 500(H) X 582(V) |
NTSC : 768(H) X 494(V)
PAL : 752(H) X 582(V) |
| H.Resolution |
380 TV Lines |
480 TV Lines |
| Minimum illumination at F2.0 |
0.3 Lux |
0.3 Lux |
| Synchronizing system (Internal) |
Internal |
| Power source |
12VDC / 80mA or less |
| Control |
Auto DC Iris control |
X |
| Scanning system |
NTSC 525 Lines PAL 625 Lines 2:1 Interlaced |
| S/N ratio |
More than 50dB (AGC Off) |
| Shutter Speed |
NTSC : 1/60~1/100,000 sec PAL : 1/50~100,000 sec |
| Gamma correction |
r=0.45 |
| White balance |
2100˚K ~ 9100˚K Auto |
| Gain Control |
4dB~30dB Auto |
| Smear Effect |
0.005% |
| MTBF |
80,000 hours |
| Lens |
Standard |
Monofocal |
f=3.6mm (92˚) |
| Varifocal |
Fixed IRIS : 4~9mm -VF49 DC IRIS : 4~9mm -VFA49 |
| Option |
Monofocal |
4.3 / 6.0 / 8.0 / 12 / 16mm |
| Varifocal |
Fixed IRIS : 2.6~6mm -VF26 DC IRIS : 2.6~6mm -VFA26 |
| Operating Temperature |
14˚F ~ 122˚F (-10˚C ~ +50˚C) |
| Humidity |
Within 90% RH |
| Output Terminal |
7 Inch lead wire |
| Measurement (mm) |
Refer to dimensions |
| Optional function |
Audio |
O |
| 940-850nm IR Sensitivity |
O |
| Weight (Approx.g) |
30 | |
|
|
|
|
