| Image sensor |
1/3" DSP Color CCD |
| Effective Pixels |
NTSC : 512(H) X 492(V) PAL : 500(H) X 582(V) |
| H.Resolution |
380 TV Lines |
| Synchronizing system |
Internal |
| Scanning system |
NTSC 525 Lines PAL 625 Lines 2:1 Interlaced |
| Video output |
1.0Vp-p Composite. 75 Ohms |
| S/N ratio |
More than 50dB (AGC Off) |
| Min. Illumination |
0.2Lux at F2.0 |
| BLC |
Automatic |
| White balance |
2100˚K ~ 8200˚K Auto |
| Gain Control |
4dB~30dB Auto |
| Smear Effect |
0.005% |
| Shutter Speed |
NTSC : 1/60~1/100,000 sec PAL : 1/50~100,000 sec |
| MTBF |
80,000 hours |
| Power source |
DC12V |
| Operating current |
90mA w/regulated 12VDC in |
| Lens Standard |
2.9 (130˚) |
| Lens Option |
3.6 (92˚), 4.3 (78˚), 6.0 (53˚), 8.0 (40˚) |
| Operating Temperature |
14˚F ~ 122˚F (-10˚C ~ +50˚C) |
| Humidity |
Within 90% RH |
| Output Terminal |
1Feet and 16feet cable with 4Pin DIN Connector |
| Measurement (mm) |
33(W) x 33(V) x 30(H) |
| Weight (Approx.g) |
150 |
| Optional Function 1 |
External Audio with C-Microphone " -35dB / mV " |
| Optional Function 2 |
Infra-Red Light sensitive without loosing the true coloration at day light | |
|
 |
|
|
Luxury Camera
Sewer Pipe Inspection Camera
