| Image Sensor |
STD : 1/3" Sony Ex-View CCD |
| Effective Pixels |
NTSC : 768(H) X 494(V) PAL : 752(H) X 582(V) |
| H.Resolution |
NTSC : 500 TV Lines (at Day) / 560 TV Lines (at Night)
PAL : 490 TV Lines (at Day) / 550 TV Lines (at Night) |
| Synchronizing system |
Internal |
| Scanning system |
NTSC 525 Lines PAL 625 Lines 2:1 Interlaced |
| Video output |
1.0Vp-p Composite. 75 Ohms |
| S/N ratio |
More than 50dB (AGC Off) |
| Min. Illumination |
0.0001 Lux at F1.2 (IR off) |
| Back Light Compensation |
ON/OFF by OSD |
| Shutter Speed |
NTSC : 1/60~1/100,000 sec PAL : 1/50~100,000 sec |
| Gamma correction |
Standard r=0.45 Switchable r=1.0 by Dip switch |
| White Balance |
2100˚K ~ 9100˚K Auto |
| Gain Control |
ATW/Push Lock/User selectable by OSD |
| Smear Effect |
0.005% |
| Power source |
24VDC or 24VAC |
| Operating current |
120mA at 24VDC (IR "off" Day) 550mA at 24VDC (IR "on" Night) |
| Lens |
4~9mm Varifocal DC iris |
| Lens option |
9~22mm Varifocal DC iris |
| Lens control |
Zoom/Focus controllable externally |
| Operating Temperature |
14˚F ~ 122˚F (-10˚C ~ +50˚C) |
| Humidity |
Within 90% RH |
| Weatherproof rating |
IP67 |
| Measurement (mm) |
121(W) X 249(V) X 380(L) |
| Weight (Approx.g) |
2200 |
| OSD Menu - RS 485 (Remote control via DVR or Controller is available) |
| White balance |
Auto(ATW)/Push Lock/User selectable (Push: 1800˚K~10,500˚K) |
| Gain Control |
Low, Middle, High, Off Selectable |
| Shutter speed |
1/60 - 1/120,000 sec (NTSC), 1/50 - 1/100,000 sec (PAL) |
| Digital Slow Shutter |
Off/2x~160x (DSS) |
| Privacy Masking |
On/Off (4 programmable zones) |
| Digital zoom |
OFF/ON 1.5x, 2x, 3x. |
| IR Spectrum |
850nm-ø10 X 30˚ X 20ea |
| Viewable distance |
Up to 70M at moonless night |
| MTBF of IR |
20,000 Hours | |
|
|
|
|
