| Image Format |
1/3" Sony Super HAD |
| Effective Pixels |
NTSC : 512(H) X 492(V) PAL : 500(H) X 582(V) |
| H.Resolution |
400 TV Lines |
| Synchronizing system |
Internal |
Internal |
| Line Lock |
Internal / Line lock (L) |
| Visible Distance at "0" lux dark (IR on) |
35M |
| LED Spectrum & IR No. |
850nm(20˚) x 35 IR |
| Power source |
DC12V version |
12VDC / 560mA or less |
| 12VDC / 24VAC |
12VDC / 530mA, Non-polarity |
| Dual power version |
24VAC / 400mA, Non-polarity |
| Special |
True Day/Night |
O |
| Dual Filter sys (Option) |
O |
| IP Rating |
IP67 |
| Scanning system |
NTSC 525 Lines PAL 625 Lines 2:1 Interlaced |
| Video output |
1.0Vp-p Composite. 75 Ohms |
| S/N ratio |
More than 50dB (AGC Off) |
| Shutter Speed |
NTSC : 1/60~1/100,000 sec PAL : 1/50~100,000 sec |
| Gamma correction |
r=0.45 |
| White balance |
2100˚K ~ 9100˚K Auto |
| Gain Control |
4dB~30dB Auto |
| Smear Effect |
0.005% |
| MTBF |
20,000 hours |
| Lens |
Standard |
Fixed IRIS : 4~9mm -VF49
DC IRIS : 4~9mm -VFA49 |
| Options |
Fixed IRIS : 2~6mm -VF26
DC IRIS : 2~6mm -VFA26 |
| Operating Temperature |
14˚F ~ 122˚F (-10˚C ~ +50˚C) |
| Humidity |
Within 90% RH |
| Output Terminal |
1foot(30cm) waterproof 4 Pin DIN-male + 1foot 4 Pin DIN-female Short cable (Total 2ft long cable set) |
| Measurement (mm) |
70φ X 95(L) w/o Hood |
| Weight (Approx.g) |
1220 |
| Dip S/W Functions |
ESC/ALC |
Yes (12 or 24 Line lock) |
| BLC On/Off |
| Flickerless On/Off |
| Internal /Line Lock |
| AWB/MWB |
| AGC Nor/Max |
| Gammar 0.45/1.0 |
| Optional Features |
True DN |
Yes |
| Dual Filter mechanism |
| External Audio |
O | |
|
|
|
|
